Health API
The endpoints of the HiveMQ Health API provide operational information about your HiveMQ broker components and extensions.
With the Health API, you can capture snapshots that show the current state of health for each node in your HiveMQ cluster. The well-structured information the API provides helps you quickly identify potential issues and maintain the smooth operation of your HiveMQ platform deployment.
Configuration
<hivemq>
<!-- ... -->
<health-api>
<enabled>true</enabled>
<listeners>
<http>
<port>8889</port>
<name>health-api-listener</name>
<bind-address>127.0.0.1</bind-address>
</http>
</listeners>
</health-api>
</hivemq>
Parameter | Default Value | Required | Description |
---|---|---|---|
|
|
Enables or disables the use of the HiveMQ Health API. The Health API is disabled by default. To allow access to the Health API, set the |
|
|
Configures one or more HTTP listeners to provide access to the HiveMQ Health API.
|
When the Health API is enabled, multiple endpoints are exposed on each configured HTTP listener:
-
/api/v1/health/
: An endpoint that reflects the system-wide health status of all components in the selected HiveMQ deployment. -
/api/v1/health/<component-name>
: An endpoint for an individual broker component. -
/api/v1/health/extensions
: An endpoint that reflects the health of all extensions in the selected HiveMQ deployment. -
/api/v1/health/extensions/<extension-id>
: An endpoint for a individual extension component.
The Health API also provides two health group endpoints that assemble data from sets of components:
-
/api/v1/health/liveness
: Liveness Check. -
/api/v1/health/readiness
: Readiness Check.
Health API endpoints are HTTP only and do not support TLS. |
HTTP response
When called, each endpoint of the Health API returns an HTTP status code and a human-readable JSON response body with additional information.
The HTTP status code reflects the overall health of the selected health component or health group.
The response body contains a JSON payload with structured information.
{
"status": "<status>",
"details": {
"<key>": "<value>"
},
"components": {
"<component-name>": {
"status": "<status>",
"components": {
"<component-name>": {
"status": "<status>",
"details": {
"<key>": "value"
}
}
}
}
}
}
Based on user feedback and continued development, upcoming versions of the HiveMQ Health API JSON payload are expected to include additional information about the health of individual components. These future additions can change the JSON payload. |
Every health response includes a mandatory status and can optionally include additional details.
Health components can have nested components that follow the same structure as the parent component. The status of the parent component is the aggregated status of all associated child components. This aggregated status of the top component determines the HTTP status code of the response. |
Status | HTTP status code | Description |
---|---|---|
|
|
The component is healthy. |
|
|
The health status of the component is unknown. |
|
|
The component is unhealthy. |
|
|
The service is unavailable. |
When you set up automated monitoring and operations, we recommend the use of the HTTP status code only. |
System Health
The system health endpoint provides an aggregated status of all available health components and health groups.
{
"status": "UP",
"components": {
"<component-name>": {
"status": "UP"
},
"livenessState": {
"status": "UP"
},
"readinessState": {
"status": "UP"
}
},
"groups": [ "liveness", "readiness" ]
}
{
"status": "DOWN",
"components": {
"<component-name>": {
"status": "DOWN"
},
"livenessState": {
"status": "UP"
},
"readinessState": {
"status": "UP"
}
},
"groups": [ "liveness", "readiness" ]
}
Health Components
Health API components help you assess the health and status of various aspects of your HiveMQ deployment.
Info
The Info health component provides general information about the HiveMQ platform.
For example, the HiveMQ version, the current log level, and the epoch timestamp of the node start.
{
"status": "UP",
"details": {
"cpuCount": 32,
"logLevel": "INFO",
"startedAt": 1693479102563,
"version": "4.19.0"
}
}
Cluster Service
The Cluster health component provides information about the connection state of your HiveMQ Cluster.
Once inter-broker communication is fully established and the node successfully joins the cluster, the cluster status reports UP
.
The information the Cluster health component provides can help you debug node synchronization. For example, to detect a node that is stuck in the join process or to detect a network split.
{
"status": "UP",
"details": {
"clusterNodes": [
"C3P0X",
"R2D2Y"
],
"clusterSize": 2,
"nodeId": "C3P0X",
"nodeState": "RUNNING"
}
}
{
"status": "DOWN",
"details": {
"clusterNodes": [
"C3P0X",
"R2D2Y"
],
"clusterSize": 2,
"nodeId": "C3P0X",
"nodeState": "JOINING"
}
}
MQTT
The MQTT health component provides information about the MQTT Listeners and their connection state.
The information the MQTT component provides is useful to ensure that all configured listeners are correctly started and ready to accept traffic.
Failure reasons are provided in the details of each listener component.
{
"status": "UP",
"components": {
"tcp-listener-1883": {
"status": "UP",
"details": {
"bindAddress": "0.0.0.0",
"isProxyProtocolSupported": false,
"isRunning": true,
"port": 1883,
"type": "TCP Listener"
}
},
"tls-tcp-listener-8883": {
"status": "UP",
"details": {
"bindAddress": "0.0.0.0",
"isProxyProtocolSupported": false,
"isRunning": true,
"port": 8883,
"type": "TCP Listener with TLS"
}
}
}
}
{
"status": "DOWN",
"components": {
"tcp-listener-1883": {
"status": "UP",
"details": {
"bindAddress": "0.0.0.0",
"isProxyProtocolSupported": false,
"isRunning": true,
"port": 1883,
"type": "TCP Listener"
}
},
"tls-tcp-listener-8883": {
"status": "DOWN",
"details": {
"bindAddress": "0.0.0.0",
"isProxyProtocolSupported": false,
"isRunning": false,
"lastFailure": "java.io.IOException: Failed to bind to /0.0.0.0:8883",
"port": 8883,
"type": "TCP Listener with TLS"
}
}
}
}
Control Center
The Control Center health component provides information about the Control Center. The details show the current Control Center configuration, the state of the Jetty server connector, and failure reasons in the details of each listener component (if applicable).
{
"status": "UP",
"details": {
"enabled": true,
"defaultLoginMechanismEnabled": true,
"maxSessionIdleTime": 14400
},
"components": {
"control-center-http-listener-8080": {
"status": "UP",
"details": {
"bindAddress": "0.0.0.0",
"isConnectorFailed": false,
"isConnectorOpen": true,
"isConnectorRunning": true,
"port": 8080
}
}
}
}
{
"status": "DOWN",
"details": {
"enabled": true,
"defaultLoginMechanismEnabled": true,
"maxSessionIdleTime": 14400
},
"components": {
"control-center-https-listener-8443": {
"status": "DOWN",
"details": {
"bindAddress": "0.0.0.0",
"isConnectorFailed": false,
"isConnectorOpen": true,
"isConnectorRunning": true,
"lastTlsFailure": "java.io.IOException: keystore password was incorrect",
"port": 8443
}
}
}
}
REST API
The REST API health component provides information about the HiveMQ REST API.
The details show your current REST API configuration, the state of the Jetty server connector, and failure reasons in the details of each listener component (if applicable).
{
"status": "UP",
"details": {
"authenticationEnabled": false,
"enabled": true
},
"components": {
"http-listener": {
"status": "UP",
"details": {
"bindAddress": "127.0.0.1",
"isConnectorFailed": false,
"isConnectorOpen": true,
"isConnectorRunning": true,
"port": 8888
}
},
"https-listener": {
"status": "UP",
"details": {
"bindAddress": "127.0.0.1",
"isConnectorFailed": false,
"isConnectorOpen": true,
"isConnectorRunning": true,
"port": 8443
}
}
}
}
{
"status": "DOWN",
"details": {
"authenticationEnabled": false,
"enabled": true
},
"components": {
"http-listener": {
"status": "DOWN",
"details": {
"bindAddress": "127.0.0.1",
"isConnectorFailed": true,
"isConnectorOpen": false,
"isConnectorRunning": false,
"lastFailure": "java.io.IOException: Failed to bind to /0.0.0.0:8888",
"port": 8888
}
},
"https-listener": {
"status": "UP",
"details": {
"bindAddress": "127.0.0.1",
"isConnectorFailed": false,
"isConnectorOpen": true,
"isConnectorRunning": true,
"port": 8443
}
}
}
}
Extensions
The Extensions health component provides information about your configured custom and HiveMQ Enterprise extensions.
The details provide the extension metadata and failure information. For example, the reason string when an extension fails to start or the trial mode of a HiveMQ Enterprise Extension expires.
{
"status": "UNKNOWN",
"details": {
"author": "HiveMQ",
"enabled": true,
"isEnterprise": false,
"name": "Allow All Extension",
"priority": 0,
"startPriority": 1000,
"startedAt": 1693479104646,
"version": "1.0.0"
}
}
{
"status": "DOWN",
"details": {
"author": "HiveMQ",
"enabled": false,
"isEnterprise": true,
"isTrial": true,
"isTrialExpired": false,
"lastStartupFailure": "Error in tracing configuration",
"name": "HiveMQ Enterprise Distributed Tracing Extension",
"priority": 1000,
"startPriority": 1000,
"startedAt": 1693585188163,
"version": "4.19.0"
}
}
Health Groups
It is sometimes useful to organize health components into groups that can be used for different purposes.
Health groups show the aggregated state of selected health components.
The HiveMQ liveness and readiness health groups are useful for common use cases such as
liveness and readiness probes for Kubernetes containers.
Liveness Check
The liveness
health group checks whether the deployed HiveMQ broker is currently operational, responsive, and reachable.
{ "status": "UP" }
Readiness Check
The Readiness health group checks whether the HiveMQ node is currently available to receive and process MQTT messages.
If the Cluster component and the MQTT component are both healthy, the readiness check returns the status UP
and the node can accept traffic.
If one of the components in the Readiness health group is not healthy, the readiness check returns the status OUT_OF_SERVICE
.
The out-of-service status indicates that the HiveMQ node is currently unable to accept traffic.
{
"status": "UP",
"components": {
"cluster": {
"status": "UP",
"details": {
}
},
"mqtt": {
"status": "UP",
"components": {
}
}
}
}
{
"status": "OUT_OF_SERVICE",
"components": {
"cluster": {
"status": "UP",
"details": {
}
},
"mqtt": {
"status": "DOWN",
"components": {
}
}
}
}
